Icon Features

Beauty is more than skin deep. ICON is the beefiest trailer out there in both steel and aluminum frames.
All ICON’s feature stainless steel paddle latches in ramp door and stainless steel wrapped rear corner posts.
Standard polished aluminum fenders, spread axles and drop skirting create a “drop dead gorgeous” top of the line trailer.
Beefy 5 1/2” bottom trim looks great and adds protection to vulnerable lower areas of the trailer.
Solid front corners and double tube top rail offers the strength needed in longer and taller trailers.
Standard fully finished interior feature .030 alum walls, finished ceiling and black coin flooring.
ICON is the exceptional trailer that has it all in both steel and aluminum frames. Better design, workmanship and options make ICON the trailer to have. In addition to our Bravo Big 10 plus 5 commercial construction features a long list of features come standard on ICON. Custom polished castings, aluminum wheels, polished extruded aluminum fenders, rear ramp door with stainless steel paddle latches, a fully finished interior with aluminum walls and black coin floor, a beefy tube frame and much more. ICONs are available in tags and stackers from 20′ to 34′ and goosenecks from 36′ to 52′. Don’t be afraid to dream, ICON has the longest list of custom options and packages available.
Icon Gooseneck/Fifth Wheel Standards
- Dexter Torsion Axles
- Spread Axle Configuration
- Trailer Rated Radial Tires
- Aluminum Wheels
- Extruded Aluminum Fenders
- Z-Tech Undercoated Frame
- Tube Main Frame & Wall Posts 16″ O.C.
- ICON 16″ O.C. Tubular Roof Structure
- 2-Speed Manual Landing Gear
- VHB .030 Aluminum Exterior
- 5-1/2″ Super Duty Bottom Trim
- Stainless Wrapped Rear Steel Header & Corner Posts
- Aluminum Roof
- Polished Cast Corners w/ Stainless Insert
- Stainless Steel Front Corners
- 3/4″ Engineered Flooring
- 3/8″ Engineered Walls
- 48″ ICON Side Door w/ Flushlock
- Clear Lens LED Exterior Lighting
- 2 – Roof Vents
- 2 – Premium LED Dome Lights w/SS Bezel
- 3-Way 12V Wall Switches
- 1 – LED Light Inside Riser Compartment
- ATP Exterior Riser Wall w/40″ x 32″ Access Door
- Ramp Door w/ Keyed Paddle Latch
- Rubber Hinge Cover
- Beavertail
- Black Coin Floor & Ramp Door
- 030 Aluminum Interior Walls
- White Vinyl Ceiling
- 4 – Recessed D-Rings
- Bravo “Big 10” Plus 5
Icon Tag Standards
- Dexter Torsion Axle
- Spread Axle Configuration
- Trailer Rated Radial Tires
- Aluminum Wheels
- Extruded Aluminum Fenders
- Z-Tech Undercoated FRame
- Tube Main Frame & Wall Posts 16″ O.C.
- ICON 16″ O.C. Tubular Roof Structure
- Zinc Tongue Jack w/ Sandfoot
- VHB .030 Aluminum Exterior
- 5-1/2″ Super Duty Bottom Trim
- Stainless Wrapped Rear Steel Header & Corner Posts
- Aluminum Roof
- Polished Cast Corners w/ Stainless Insert
- Stainless Steel Front Corners
- 3/4″ Engineered Flooring
- 3/8″ Engineered Walls
- 48″ ICON Side Door w/ Flushlock
- Clear Lens LED Exterior Lighting
- 2 – Roof Vents
- 2 – Premium LED Dome Lights w/SS Bezel
- 3-way 12V Wall Switches
- 36″ ATP Stoneguard
- Ramp Door w/ Keyed Paddle Latch
- Rubber Hinge Cover
- Beavertail
- Black Coin Floor & Ramp Door
- 030 Aluminum Interior Walls
- White Vinyl Ceiling
- 4 – Recessed D-Rings
- Bravo “Big 10” Plus 5

Icon Features
Beauty is more than skin deep. ICON is the beefiest trailer out there in both steel and aluminum frames.
All ICON’s feature stainless steel paddle latches in ramp door and stainless steel wrapped rear corner posts.
Standard polished aluminum fenders, spread axles and drop skirting create a “drop dead gorgeous” top of the line trailer.
Beefy 5 1/2” bottom trim looks great and adds protection to vulnerable lower areas of the trailer.
Solid front corners and double tube top rail offers the strength needed in longer and taller trailers.
Standard fully finished interior feature .030 alum walls, finished ceiling and black coin flooring.
ICON is the exceptional trailer that has it all in both steel and aluminum frames. Better design, workmanship and options make ICON the trailer to have. In addition to our Bravo Big 10 plus 5 commercial construction features a long list of features come standard on ICON. Custom polished castings, aluminum wheels, polished extruded aluminum fenders, rear ramp door with stainless steel paddle latches, a fully finished interior with aluminum walls and black coin floor, a beefy tube frame and much more. ICONs are available in tags and stackers from 20′ to 34′ and goosenecks from 36′ to 52′. Don’t be afraid to dream, ICON has the longest list of custom options and packages available.

Icon Gooseneck/Fifth Wheel Standards
- Dexter Torsion Axles
- Spread Axle Configuration
- Trailer Rated Radial Tires
- Aluminum Wheels
- Extruded Aluminum Fenders
- Z-Tech Undercoated Frame
- Tube Main Frame & Wall Posts 16″ O.C.
- ICON 16″ O.C. Tubular Roof Structure
- 2-Speed Manual Landing Gear
- VHB .030 Aluminum Exterior
- 5-1/2″ Super Duty Bottom Trim
- Stainless Wrapped Rear Steel Header & Corner Posts
- Aluminum Roof
- Polished Cast Corners w/ Stainless Insert
- Stainless Steel Front Corners
- 3/4″ Engineered Flooring
- 3/8″ Engineered Walls
- 48″ ICON Side Door w/ Flushlock
- Clear Lens LED Exterior Lighting
- 2 – Roof Vents
- 2 – Premium LED Dome Lights w/SS Bezel
- 3-Way 12V Wall Switches
- 1 – LED Light Inside Riser Compartment
- ATP Exterior Riser Wall w/40″ x 32″ Access Door
- Ramp Door w/ Keyed Paddle Latch
- Rubber Hinge Cover
- Beavertail
- Black Coin Floor & Ramp Door
- 030 Aluminum Interior Walls
- White Vinyl Ceiling
- 4 – Recessed D-Rings
- Bravo “Big 10” Plus 5
Icon Gooseneck/Fifth Wheel Standards
- Dexter Torsion Axle
- Spread Axle Configuration
- Trailer Rated Radial Tires
- Aluminum Wheels
- Extruded Aluminum Fenders
- Z-Tech Undercoated FRame
- Tube Main Frame & Wall Posts 16″ O.C.
- ICON 16″ O.C. Tubular Roof Structure
- Zinc Tongue Jack w/ Sandfoot
- VHB .030 Aluminum Exterior
- 5-1/2″ Super Duty Bottom Trim
- Stainless Wrapped Rear Steel Header & Corner Posts
- Aluminum Roof
- Polished Cast Corners w/ Stainless Insert
- Stainless Steel Front Corners
- 3/4″ Engineered Flooring
- 3/8″ Engineered Walls
- 48″ ICON Side Door w/ Flushlock
- Clear Lens LED Exterior Lighting
- 2 – Roof Vents
- 2 – Premium LED Dome Lights w/SS Bezel
- 3-way 12V Wall Switches
- 36″ ATP Stoneguard
- Ramp Door w/ Keyed Paddle Latch
- Rubber Hinge Cover
- Beavertail
- Black Coin Floor & Ramp Door
- 030 Aluminum Interior Walls
- White Vinyl Ceiling
- 4 – Recessed D-Rings
- Bravo “Big 10” Plus 5

Icon Trailers
You Deserve the Best!
Whether it’s for work or play there is an ICON trailer for you. Bravo trailers are built by a team who actually uses trailers themselves. Racers, hobbyists and tradesman-we at Bravo know what our customers demand from a quality trailer. Great looking trailers that exceed your expectations are our specialty. They look better, tow better, last longer and are worth more at trade in time. We make dreams come true!
Picking the Perfect
ICON Trailer
Is Easy!
Contacting your authorized Bravo dealer is a great first step. They are experts in trailering and will help you design the perfect custom ICON trailer. Your dealer and the Bravo team will work with you designing the perfect custom trailer and we will build it right and deliver it on time. Our steadfast goal is to exceed your expectations!

Let Bravo Create the Perfect Trailer to Fit Your Needs
Our Options Work Better!
ICON Options
ICON
Tag Models Available:
20′ to 34’L
Gooseneck/Fifth Wheel Models Available:
36′ to 52’L
ICON Stacker
Tag Models Available:
20′ to 34’L
Gooseneck/Fifth Wheel Models Available:
36′ to 48’L
Awning –
Axles, Running Gear & Wheels
- Aluminum Wheels –
- Axle Spread Configurations –
- Electric/Hydraulic Disc Brakes (Available on 6k, 7k or 8k axles) –
Exterior Metal Options
- Exterior Colors –
- .050 Exterior Metal – White or Black
- Stainless Steel Sides –
- ATP Finished Under Riser with LED Light –
- Stainless Steel Gooseneck Front-End –
Framework Options
- Extra Height – 6″ to 48″ Available
- ATP Covered A-Frame –
- Heavy Duty Rear Bogey Wheels –
- Reverse Beavertail –
Jacks
- 12V Nose Jack –
- Hydraulic Nose Jack for Stacker & Gooseneck –
- Drop Down Jacks –
- Set Back Tongue Jack –
12V Lighting & Options
- LED Side Docking Light –
- Triple Tail Light with Backup –
- 12V Rear Loading Light –
- 12V Kill Switch –
- In-Floor 12V Battery –
110 Electrical, Upgrades & Packages –
- Additional Lighting –
- 500W Quartz Loading Lights –
Custom Cabinets, Closets & Tool Boxes –
Doors
Concession Doors & Windows –
Exterior Side Doors & Upgrades
- 60″ Double Side Door –
- RV Side Door w/Window & Screen –
- Side Door Steps –
- Aluminum Step Well –
- 54″ Over Wheel Well Door –
- Swing Up Door w/Removable Wheel Box Aluminum Models –
Ramp Door Options
- Aluminum Transition Flap –
- Aluminum Ramp Door –
- Cold Curtain –
- Sliding Rear Glass Doors –
- Stainless Ext. Rear Ramp Door –
- Turnkey 10′ Folding Ramps –
- Dragster Loading Package –
- Extended Flap for Ramp Door
Ramp Over Wheel Wells & Ramp Ups –
Utility/Misc. Doors
- Access Doors –
- Pocket Door in Partition Wall –
Finished Interior Options
- Insulation –
- ATP or Carpeted Wheel Boxes –
- Carpeted Walls & Aluminum Ceiling –
Flooring Options –
Generators –
- Generator Prep –
- Fuel Tank Under Floor –
HVAC
- A/C –
- Heat –
Roof Options
- Roof Observation Deck & Ladder –
- Roof Escape Hatch –
Spare Tire Mounts –
- In-Floor Spare Tire Storage –
- Tire Racks –
Storage / Tool Box –
Tie Downs
- Airline Track –
- D-Ring & E-Track Tie Downs –
Vents
- Roof Vents –
- Aluminum Sidewall Vents –
Winches –
Windows –
Wing ICON Rear –
Custom Options
- Air Line with Drain –
- Rear Camera –
- Sinks, Plumbing & Bathroom –
- Exterior Marine Speakers –
- And Much More
Hundreds more and a custom shop to install them!
ICON Trailer Specifications
Visit the Shopping Tools Tab for Printable Specs
Model code: IC8520TA3
IC = ICON Model, 85 = 8.5′ Width, 20 = 20′ Length, TA = Tandem Axles, 3 = Axle Rating
Specifications subject to change. Curb weights based on standard models with no options.
Details | IC8520TA3 | IC8524TA3 | IC8528TA3 | IC8524TA4 | IC8528TA4 | IC8532TA4 | IC8530TA5 | IC8532TA5 | IC8530TTA4 | IC8532TTA4 | IC8532TTA5 | IC8534TTA5 | ICG/F8540TTA4 | ICG/F8544TTA4 | ICG/F8548TTA4 | ICG/F8540TTA5 | ICG/F8544TTA5 | ICG/F8548TTA5 | ICG/F8550TTA5 | ICS8524TTA4 | ICS8526TTA4 | ICS8524TTA5 | ICS8526TTA5 | ICS8528TTA5 | ICS8530TTA5 | ICS8532TTA5 | ICG/FS8536TTA6 | ICG/FS8538TTA6 | ICG/FS8540TTA6 | ICG/FS8542TTA6 | ICG/FS8544TTA6 | ICG/FS8546TTA6 | ICG/FS8548TTA6 | AIC8520TA3 | AIC8524TA3 | AIC8528TA3 | AIC8524TA4 | AIC8528TA4 | AIC8532TA4 | AIC8530TA5 | AIC8532TA5 | AIC8530TTA4 | AIC8532TTA4 | AIC8532TTA5 | AIC8534TTA5 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Tire Size | 15” Radial | 15” Radial | 15” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 17.5” Radial | 17.5” Radial | 17.5” Radial | 17.5” Radial | 17.5” Radial | 17.5” Radial | 17.5” Radial | 15” Radial | 15” Radial | 15” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial | 16” Radial |
Brakes | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric |
Tube Frame | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 8” Tube | 8” Tube | 6” Tube | 6” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 6” Tube | 8” Tube | 8” Tube | 8” Tube | 8” Tube |
Hitch Ball Size | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” | 2-5/16” |
Curb Weight | 4594# | 5202# | 5710# | 5232# | 5740# | 6232# | 6086# | 6332# | 6406# | 6652# | 6506# | 6752# | 8993# | 9491# | 10354# | 9087# | 9621# | 10484# | 10745# | 9240# | 10010# | 9390# | 10160# | 10930# | 11700# | 12320# | 12816# | 13528# | 14240# | 14952# | 15664# | 16376# | 17088# | 3745# | 4214# | 4594# | 4242# | 4620# | 4986# | 4970# | 5126# | 5429# | 5651# | 5781# | 5964# |
Hitch Weight | 621# | 703# | 771# | 707# | 775# | 842# | 822# | 855# | 865# | 898# | 878# | 912# | 2250# | 2373# | 2589# | 2272# | 2406# | 2621# | 2687# | 1386# | 1501# | 1408# | 1501# | 1640# | 1755# | 1848# | 2563# | 2706# | 2848# | 2990# | 3133# | 3275# | 3418# | 487# | 548# | 597# | 551# | 600# | 648# | 646# | 667# | 706# | 735# | 752# | 775# |
GVWR | 9990# | 9990# | 9990# | 12000# | 12000# | 12000# | 14000# | 14000# | 18000# | 18000# | 21000# | 21000# | 18000# | 18000# | 18000# | 21000# | 21000# | 21000# | 21000# | 18000# | 18000# | 21000# | 21000# | 21000# | 21000# | 21000# | 24000# | 24000# | 24000# | 24000# | 24000# | 24000# | 24000# | 9990# | 9990# | 9990# | 12000# | 12000# | 12000# | 14000# | 14000# | 18000# | 18000# | 21000# | 21000# |
Payload Capacity | 5396# | 4788# | 4280# | 6768# | 6260# | 5768# | 7914# | 7668# | 11594# | 11348# | 14494# | 14248# | 9007# | 8509# | 7046# | 11913# | 11379# | 10516# | 10255# | 8760# | 7990# | 11610# | 10840# | 10070# | 9300# | 8680# | 11184# | 10472# | 9760# | 9048# | 8336# | 7624# | 6912# | 6245# | 5776# | 5396# | 7758# | 7380# | 7014# | 9030# | 8874# | 12571# | 12349# | 15219# | 15036# |
Overall Length | 24’-2” | 28’-2” | 32’-2” | 28’-2” | 32’-2” | 36’-2” | 30’-2” | 32’-2” | 30’-2” | 32’-2” | 32’-2” | 34’-2” | 40’-6” | 44’-6” | 48’-6” | 40’-6” | 44’-6” | 48’-6” | 50’6” | 28’-2” | 30’-2” | 28’-2” | 30’-2” | 32’-2” | 34’-2” | 36’-2” | 36’-6” | 38’-6” | 40’-6” | 42’-6” | 44’-6” | 46’-6” | 48’6” | 24’-8” | 28’-8” | 32’-8” | 28’-8” | 32’-8” | 36’-8” | 34’-8” | 36’-8” | 34’-8” | 36’-8” | 36’-8” | 38′-8” |
Overall Width | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” | 8’-6” |
Overall Height | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’3” | 9’3” | 9’1” | 9’1” | 9’1” | 9’3” | 9’3” | 9’3” | 9’5” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 13’4” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” | 9’1” |
Exterior Box Width | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” | 8’-4” |
Interior Length | 19’-7” | 23’-7” | 27’-7” | 23’-7” | 27’-7” | 31’-7” | 29’-7” | 31’-7” | 29’-7” | 31’-7” | 31’-7” | 33’-7” | 32’ | 36’ | 40’ | 32’ | 36’ | 40’ | 42’ | 23’-7” | 25’-7” | 23’-7” | 25’-7” | 27’-7” | 29’-7” | 31’-7” | 28’ | 30’ | 32’ | 34’ | 36’ | 38’ | 40’ | 19’-7” | 23’-7” | 27’-7” | 23’-7” | 27’-7” | 31’-7” | 29’-7” | 31’-7” | 29’-7” | 31’-7” | 31’-7” | 33’-7” |
Interior Width | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” | 8’-1” |
Width B/W Wheel Wells | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 80-1/2” | 80-1/2” | 80-1/2” | 80-1/2” | 80-1/2” | 80-1/2” | 80-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” | 81-1/2” |
Interior Height | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 7’ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 11’1″ | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” | 6’10” |
Platfrom Height/Loading | 20″/17″ | 20″/17″ | 20″/17″ | 21″/18″ | 21″/18″ | 21″/18″ | 20″/17″ | 20″/17″ | 20″/17″ | 20″/17″ | 22″/18″ | 22″/18″ | 20″/18″ | 20″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 22″/18″ | 20″/17″ | 20″/17″ | 20″/17″ | 21″/18″ | 21″/18″ | 21″/18″ | 21″/18″ | 21″/18″ | 23″/20″ | 23″/20″ | 23″/20″ | 23″/20″ |
Rear Door | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP | RAMP |
Rear Door Width | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ | 92″ |
Rear Door Height | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 96″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ | 82″ |
Side Door Width | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ | 48″ |
Side Door Height | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ | 78″ |
Cross Members O.C. | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C |
Wall Posts O.C. | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C |
Roof Members O.C. | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C | 16”O.C |
